FEATURES:
1.Square wave power supply with good quality,short zero-crossing time of current ensure stable arc.
2.Super capacity of oxide film removing with continuously adjustable Clean width enable nice weld bead.
3.Good arc stiffness,little nosie,easy wire feeding and good formation.
4. Digital Display,2T/4T trigger ,AC/DC.Pluse,TIG and MMA are available,Current can be adjusted by pedal control. (pedal control can be extra added)
5.Stable arc,beautiful welding surface and easy operation.
6.Be able to weld mild steel, stainless steel,copper and Titanor metal etc. by DC function.also be able to weld aluminium and aluminium-alloy by AC function.
7.Adjustable pluse frequency and pluse current output,suit for many kinds of welding requirement.
Applicable Materials: Aluminum and aluminum-magnesium alloy, alloy steel, carbon steel,copper, titanium alloy.
Scope of Aplication: Auto parts,Motorcycles,bicycles, furniture appliances
PARAMETERS
Model | TIG 200P AC/DC |
Input power voltage/frequency(V/Hz) | AC220±15% (Single Phase,50/60Hz) |
Rated input power capacity(KVA) | 4.5 |
Output current Range (A) | 5-200 |
Working Voltage (V) | 18 |
No-load voltage(V) | 56 |
Duty Cycle (%) | 60 |
Arc-starting | HF |
Efficiency | 85 |
Insulation Class | F |
Power Factor(CosΦ) | 0.93 |
Weight(Kg) | 20 |
Dimensions(MM) | 509X328X330 |
Protection Class | IP23 |
Postflow Time (S) | 0-2 |
Clean Width | 20-80 |
Down-slope Time(S) | 0-10 |
Postflow Time (S) | 1-10 |
Romote Control | YES |
Welding Thickness(MM) | 0.5-10 |
Base Current | 10-90 |
Pluse Frequency | 0.5-300 |
