Technical Parameters
| Power voltage (V): | 380V ± 10% | Frequency | 50/60HZ |
| Rated input power capactiy | 40KVA | Output current range | 20-500A |
| Rated output voltage | 28V | Duty cycle | 60% |
| Efficiency | 85% | Power factor | 0.93 |
| Insulation class | F | Protection class | IP23 |
| Weight | 32.4KGS | Overall dimension | 480*203*369MM |
