Features:
Stable output current, reliable welding, light weight, power-saving, non electromagnetic noise, large output power, suitable for arc gouging and manual arc welding.
High efficiency, power saving, portable size, excellent dynamic characteristics
Large output current, strong air gouging strength
Stable arc, quality gouging groove
Small size, light weight, easy to install, easy to operate
Stable performance, voltage auto-compensation function
Long-time welding function available, overload protection function
Parameters:
ModelItem | Unit | ARC1000 (J62) |
Power supply voltage | V | 3-phase380VAC±15% |
Frequency | Hz | 50/60 |
Rated input capacity | KVA | 53 |
Rated input current | A | 82 |
No-load voltage | V | 82±3 |
Ouput current range | A | 100-1000 |
Rated output voltage | V | 44 |
Arc force range | A | 15-200 |
Thermal are lgnition current | A | 15-300 |
Duty cycle | % | 60 |
Effciency | % | 85 |
Power factor(COSφ) |
| 0.94 |
Insulation class |
| F |
Protection class |
| IP21S |
Weight | Kg | 84 |
Size | mm | 840x363x750 |
